Description
| Max Flowrate | 8 GPM / 30 LPM |
|---|---|
| Power Type | 12V DC |
| Compatible Fluids | Diesel, Gasoline, Kerosene, Biodiesel up to B20, E15 |
| Inlet Size / Connection / Thread | 1 ” / Female / NPT |
| Outlet Size / Connection / Thread | 0.75 ” / Female / NPT |
| Mounting Size / Thread / Type | 2″ / NPT / Bung Mount |
| Duty Cycle (min) | 15 min on / 15 min off |
| Power Source | Electrical |
| Motor Power (HP) | 1/12 |
| Max Current (A) | 15 A |
| Thermal Protection Switch | Yes |
| Self Priming | Yes |
| Suction Lift (ft.) | 6 ‘ |
| Dry Vacuum (in. Hg) | 3.5 |
| Operating Temperature Range (°F) | — |
| Discharge Head (ft) | 32 ‘ |
| Strainer Mesh Size (Micron) | 20×20 |
| Max Operating Pressure (PSI) | 12 |
| Viscosity Range (cSt) | .5 to 5.5 |
