Specification
- Flow: Capable of up to 60 GPM (227 LPM); Bi-directional Flow
- Flange Connections: 1 1/2” NPT Flange; 1” & 2” Options
- Linear Accuracy: Capable of ± 0.15% of over the full flow range
- Repeatability: Capable of 0.02% (constant operation conditions with 700SP meters & mechanical registration, using 1 CPS test fluid)
- Viscosity: Will accurately measure liquids up to 1,500,000 SSU (325,000 CPS)
- Working Pressure: 150 PSI (10.5 BAR)
- Working Temperature: 40 to 160°F (- 40 to 71°C)
Meter Types
700 IC – Industrial Products Carbon Bearings
Materials of Construction: Anodized Aluminum, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, Simriz*, PTFE.The 700IC rotary flow meter is designed to meter industrial chemicals, general solvents, water, and other non-lubricating liquids such as alcohol, acetones, ethanol, naphtha, xylene, MEK, touluene, deionized water, demineralized water, potable water, etc. It is available in 1.5″ to 4″ sizes.
700 IP – Industrial Products Stainless Steel Bearings
Materials of Construction: Anodized Aluminum, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, Simriz*, PTFE. The 700IC rotary flow meter is designed to meter industrial chemicals, general solvents, water, and other non-lubricating liquids such as alcohol, acetones, ethanol, naphtha, xylene, MEK, touluene, deionized water, demineralized water, potable water, etc. It is available in 1.5″ to 4″ sizes.
700 SPA – Standard Petroleum Aviation
Materials of Construction: Materials of Construction: Anodized Aluminum, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, FKM. The 700 SPA rotary flow meter is designed to meter aviation gasoline, gasoline, jet fuels, fuel oils, diesel, bio-diesel, kerosene, and naptha. It is available in 1.5″ to 6″ sizes.
700 SP – Standard Petroleum Meters
Materials of Construction: Anodized Aluminum, Stainless Steel, Treated Stainless Steel, Ni-Resist, FKM. The 700 SP rotary flow meter is designed to meter petroleum products such as gasoline, fuel oils, diesel, bio-diesel, kerosene, vegetable oils, soy oil, motor oils, ethylene glycol (anti-freeze), etc. It is available in 1.5″ to 4″ sizes.
