Specification
- Flow: Capable of up to 100 GPM (380 LPM); Bi-directional Flow
- Flange Connections: 2” NPT Flange; 1 1/2” Option
- Linear Accuracy: Capable of ± 0.15% of over the full flow range
- Repeatability: Capable of 0.02% (constant operation conditions with 700SP meters & mechanical registration, using 1 CPS test fluid)
- Viscosity: Will accurately measure liquids up to 1,500,000 SSU (325,000 CPS)
- Working Pressure: 150 PSI (10.5 BAR)
- Working Temperature: 40 to 160°F (- 40 to 71°C)
Meter Types
700 SPD – Standard Petroleum Ductile Nodular Iron
Materials of Construction: Ductile Iron, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, FKM, Simriz*. The 700 SPD rotary flow meter is designed to meter refined petroleum products such as aviation gasoline, ethanol blends, methanol blends, gasoline, fuel oils, diesel, bio-diesel, kerosene, vegetable oils, soy oil, etc. It is available in 2″ to 4″ sizes.
700 IC – Industrial Products Carbon Bearings
Materials of Construction: Anodized Aluminum, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, Simriz*, PTFE.The 700IC rotary flow meter is designed to meter industrial chemicals, general solvents, water, and other non-lubricating liquids such as alcohol, acetones, ethanol, naphtha, xylene, MEK, touluene, deionized water, demineralized water, potable water, etc. It is available in 1.5″ to 4″ sizes.
700 SPA – Standard Petroleum Aviation
Materials of Construction: Materials of Construction: Anodized Aluminum, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, FKM.The 700IC rotary flow meter is designed to meter industrial chemicals, general solvents, water, and other non-lubricating liquids such as alcohol, acetones, ethanol, naphtha, xylene, MEK, touluene, deionized water, demineralized water, potable water, etc. It is available in 1.5″ to 4″ sizes.
700 IP – Industrial Products Stainless Steel Bearings
Materials of Construction: Anodized Aluminum, Stainless Steel, Treated Stainless Steel, Ni-Resist, Simriz*, PTFE.The 700 IP rotary flow meter is designed to meter industrial chemicals, general solvents, and many other liquids such as liquid sugars, corn syrup, soy bean oil, latex products, adhesives, etc. It is available in 1.5″ to 4″ sizes.
700 AF – All Ferrous
Materials of Construction: Ductile Iron, Stainless Steel, Carbon Graphite, Ni-Resist, PTFE.The 700 AF rotary flow meter is designed to meter industrial chemicals, solvents, pesticides, fertilizer, chlorinated solvents, paints, inks, alcohols, molasses, corn syrup, and more. It is available in 2″ to 4″ sizes.
700 SS – Stainless Steel
Materials of Construction: 316 Stainless Steel, Carbon Graphite, Treated Stainless Steel, Simriz*, PTFE.The 700 SS rotary flow meter is designed to meter all the same liquids as the SP, SPA, SPD, IP, IC, and AF flow meters, but includes special handling for fluids such has nitric, phosphorus and glacial acetic acids, anti-icing fluids, vinegar, fruit juices, etc. It is available in 2″ size.
700 SSD – Stainless Steel DEF
Materials of Construction: Stainless Steel, Treated Stainless Steel, Ryton, EPDM.The 700 SSD rotary flow meter is designed to meter diesel exhaust fluid (DEF), AdBlue, AUS 32, and ARLA 32. It is available in 2″ size.
700 LP – Liquefied Petroleum Gas
Materials of Construction: Anodized Aluminum, Stainless Steel, Ni-Resist, Buna. The 700 LP rotary flow meter is designed for metering liquefied petroleum gas (LP/LPG) and NH3. It is available in 2″ size.
700 SPA – Standard Petroleum Aviation
Materials of Construction: Anodized Aluminum, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, FKM. The 700 SPA rotary flow meter is designed to meter aviation gasoline, gasoline, jet fuels, fuel oils, diesel, bio-diesel, kerosene, and naptha. It is available in 1.5″ to 6″ sizes.
700 SP – Standard Petroleum Meters
Materials of Construction: Anodized Aluminum, Stainless Steel, Treated Stainless Steel, Ni-Resist, FKM. The 700 SP rotary flow meter is designed to meter petroleum products such as gasoline, fuel oils, diesel, bio-diesel, kerosene, vegetable oils, soy oil, motor oils, ethylene glycol (anti-freeze), etc. It is available in 1.5″ to 4″ sizes.
