Specification
- Flow: Capable of up to 150 GPM (567 LPM); Bi-directional Flow
- Flange Connections: 2” NPT Flange;
- Linear Accuracy: Capable of ± 0.15% of over the full flow range
- Repeatability: Capable of 0.02% (constant operation conditions with 700SP meters & mechanical registration, using 1 CPS test fluid)
- Viscosity: Will accurately measure liquids up to 1,500,000 SSU (325,000 CPS)
- Working Pressure: 150 PSI (10.5 BAR)
- Working Temperature: 40 to 160°F (- 40 to 71°C)
Meter Types
700 SPD – Standard Petroleum Ductile Nodular Iron
Materials of Construction: Ductile Iron, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, FKM, Simriz*.The 700 SPD rotary flow meter is designed to meter refined petroleum products such as aviation gasoline, ethanol blends, methanol blends, gasoline, fuel oils, diesel, bio-diesel, kerosene, vegetable oils, soy oil, etc. It is available in 2″ to 4″ sizes.
700 SPA – Standard Petroleum Aviation
Materials of Construction: Anodized Aluminum, Stainless Steel, Carbon Graphite, Treated Stainless Steel, Ni-Resist, FKM.The 700 SPA rotary flow meter is designed to meter aviation gasoline, gasoline, jet fuels, fuel oils, diesel, bio-diesel, kerosene, and naptha. It is available in 1.5″ to 6″ sizes.
